This file contains all the functions prototypes for the DMA2D firmware library. More...
#include "stm32f4xx.h"
Go to the source code of this file.
Classes | |
| struct | DMA2D_InitTypeDef |
| DMA2D Init structure definition. More... | |
| struct | DMA2D_FG_InitTypeDef |
| struct | DMA2D_BG_InitTypeDef |
Macros | |
| #define | DMA2D_M2M ((uint32_t)0x00000000) |
| #define | DMA2D_M2M_PFC ((uint32_t)0x00010000) |
| #define | DMA2D_M2M_BLEND ((uint32_t)0x00020000) |
| #define | DMA2D_R2M ((uint32_t)0x00030000) |
| #define | IS_DMA2D_MODE(MODE) |
| #define | DMA2D_ARGB8888 ((uint32_t)0x00000000) |
| #define | DMA2D_RGB888 ((uint32_t)0x00000001) |
| #define | DMA2D_RGB565 ((uint32_t)0x00000002) |
| #define | DMA2D_ARGB1555 ((uint32_t)0x00000003) |
| #define | DMA2D_ARGB4444 ((uint32_t)0x00000004) |
| #define | IS_DMA2D_CMODE(MODE_ARGB) |
| #define | DMA2D_Output_Color ((uint32_t)0x000000FF) |
| #define | IS_DMA2D_OGREEN(OGREEN) ((OGREEN) <= DMA2D_Output_Color) |
| #define | IS_DMA2D_ORED(ORED) ((ORED) <= DMA2D_Output_Color) |
| #define | IS_DMA2D_OBLUE(OBLUE) ((OBLUE) <= DMA2D_Output_Color) |
| #define | IS_DMA2D_OALPHA(OALPHA) ((OALPHA) <= DMA2D_Output_Color) |
| #define | DMA2D_OUTPUT_OFFSET ((uint32_t)0x00003FFF) |
| #define | IS_DMA2D_OUTPUT_OFFSET(OOFFSET) ((OOFFSET) <= DMA2D_OUTPUT_OFFSET) |
| #define | DMA2D_pixel ((uint32_t)0x00003FFF) |
| #define | DMA2D_Line ((uint32_t)0x0000FFFF) |
| #define | IS_DMA2D_LINE(LINE) ((LINE) <= DMA2D_Line) |
| #define | IS_DMA2D_PIXEL(PIXEL) ((PIXEL) <= DMA2D_pixel) |
| #define | OFFSET ((uint32_t)0x00003FFF) |
| #define | IS_DMA2D_FGO(FGO) ((FGO) <= OFFSET) |
| #define | IS_DMA2D_BGO(BGO) ((BGO) <= OFFSET) |
| #define | CM_ARGB8888 ((uint32_t)0x00000000) |
| #define | CM_RGB888 ((uint32_t)0x00000001) |
| #define | CM_RGB565 ((uint32_t)0x00000002) |
| #define | CM_ARGB1555 ((uint32_t)0x00000003) |
| #define | CM_ARGB4444 ((uint32_t)0x00000004) |
| #define | CM_L8 ((uint32_t)0x00000005) |
| #define | CM_AL44 ((uint32_t)0x00000006) |
| #define | CM_AL88 ((uint32_t)0x00000007) |
| #define | CM_L4 ((uint32_t)0x00000008) |
| #define | CM_A8 ((uint32_t)0x00000009) |
| #define | CM_A4 ((uint32_t)0x0000000A) |
| #define | IS_DMA2D_FGCM(FGCM) |
| #define | IS_DMA2D_BGCM(BGCM) |
| #define | CLUT_CM_ARGB8888 ((uint32_t)0x00000000) |
| #define | CLUT_CM_RGB888 ((uint32_t)0x00000001) |
| #define | IS_DMA2D_FG_CLUT_CM(FG_CLUT_CM) (((FG_CLUT_CM) == CLUT_CM_ARGB8888) || ((FG_CLUT_CM) == CLUT_CM_RGB888)) |
| #define | IS_DMA2D_BG_CLUT_CM(BG_CLUT_CM) (((BG_CLUT_CM) == CLUT_CM_ARGB8888) || ((BG_CLUT_CM) == CLUT_CM_RGB888)) |
| #define | COLOR_VALUE ((uint32_t)0x000000FF) |
| #define | IS_DMA2D_FG_CLUT_SIZE(FG_CLUT_SIZE) ((FG_CLUT_SIZE) <= COLOR_VALUE) |
| #define | IS_DMA2D_FG_ALPHA_VALUE(FG_ALPHA_VALUE) ((FG_ALPHA_VALUE) <= COLOR_VALUE) |
| #define | IS_DMA2D_FGC_BLUE(FGC_BLUE) ((FGC_BLUE) <= COLOR_VALUE) |
| #define | IS_DMA2D_FGC_GREEN(FGC_GREEN) ((FGC_GREEN) <= COLOR_VALUE) |
| #define | IS_DMA2D_FGC_RED(FGC_RED) ((FGC_RED) <= COLOR_VALUE) |
| #define | IS_DMA2D_BG_CLUT_SIZE(BG_CLUT_SIZE) ((BG_CLUT_SIZE) <= COLOR_VALUE) |
| #define | IS_DMA2D_BG_ALPHA_VALUE(BG_ALPHA_VALUE) ((BG_ALPHA_VALUE) <= COLOR_VALUE) |
| #define | IS_DMA2D_BGC_BLUE(BGC_BLUE) ((BGC_BLUE) <= COLOR_VALUE) |
| #define | IS_DMA2D_BGC_GREEN(BGC_GREEN) ((BGC_GREEN) <= COLOR_VALUE) |
| #define | IS_DMA2D_BGC_RED(BGC_RED) ((BGC_RED) <= COLOR_VALUE) |
| #define | DMA2D_IT_CE DMA2D_CR_CEIE |
| #define | DMA2D_IT_CTC DMA2D_CR_CTCIE |
| #define | DMA2D_IT_CAE DMA2D_CR_CAEIE |
| #define | DMA2D_IT_TW DMA2D_CR_TWIE |
| #define | DMA2D_IT_TC DMA2D_CR_TCIE |
| #define | DMA2D_IT_TE DMA2D_CR_TEIE |
| #define | IS_DMA2D_IT(IT) |
| #define | DMA2D_FLAG_CE DMA2D_ISR_CEIF |
| #define | DMA2D_FLAG_CTC DMA2D_ISR_CTCIF |
| #define | DMA2D_FLAG_CAE DMA2D_ISR_CAEIF |
| #define | DMA2D_FLAG_TW DMA2D_ISR_TWIF |
| #define | DMA2D_FLAG_TC DMA2D_ISR_TCIF |
| #define | DMA2D_FLAG_TE DMA2D_ISR_TEIF |
| #define | IS_DMA2D_GET_FLAG(FLAG) |
| #define | DEADTIME ((uint32_t)0x000000FF) |
| #define | IS_DMA2D_DEAD_TIME(DEAD_TIME) ((DEAD_TIME) <= DEADTIME) |
| #define | LINE_WATERMARK DMA2D_LWR_LW |
| #define | IS_DMA2D_LineWatermark(LineWatermark) ((LineWatermark) <= LINE_WATERMARK) |
| #define | NO_MODIF_ALPHA_VALUE ((uint32_t)0x00000000) |
| #define | REPLACE_ALPHA_VALUE ((uint32_t)0x00000001) |
| #define | COMBINE_ALPHA_VALUE ((uint32_t)0x00000002) |
| #define | IS_DMA2D_FG_ALPHA_MODE(FG_ALPHA_MODE) |
| #define | IS_DMA2D_BG_ALPHA_MODE(BG_ALPHA_MODE) |
Functions | |
| void | DMA2D_DeInit (void) |
| Deinitializes the DMA2D peripheral registers to their default reset values. More... | |
| void | DMA2D_Init (DMA2D_InitTypeDef *DMA2D_InitStruct) |
| Initializes the DMA2D peripheral according to the specified parameters in the DMA2D_InitStruct. More... | |
| void | DMA2D_StructInit (DMA2D_InitTypeDef *DMA2D_InitStruct) |
| void | DMA2D_StartTransfer (void) |
| Start the DMA2D transfer. More... | |
| void | DMA2D_AbortTransfer (void) |
| Aboart the DMA2D transfer. More... | |
| void | DMA2D_Suspend (FunctionalState NewState) |
| Stop or continue the DMA2D transfer. More... | |
| void | DMA2D_FGConfig (DMA2D_FG_InitTypeDef *DMA2D_FG_InitStruct) |
| Configures the Foreground according to the specified parameters in the DMA2D_FGStruct. More... | |
| void | DMA2D_FG_StructInit (DMA2D_FG_InitTypeDef *DMA2D_FG_InitStruct) |
| Fills each DMA2D_FGStruct member with its default value. More... | |
| void | DMA2D_BGConfig (DMA2D_BG_InitTypeDef *DMA2D_BG_InitStruct) |
| Configures the Background according to the specified parameters in the DMA2D_BGStruct. More... | |
| void | DMA2D_BG_StructInit (DMA2D_BG_InitTypeDef *DMA2D_BG_InitStruct) |
| Fills each DMA2D_BGStruct member with its default value. More... | |
| void | DMA2D_FGStart (FunctionalState NewState) |
| Start the automatic loading of the CLUT or abort the transfer. More... | |
| void | DMA2D_BGStart (FunctionalState NewState) |
| Start the automatic loading of the CLUT or abort the transfer. More... | |
| void | DMA2D_DeadTimeConfig (uint32_t DMA2D_DeadTime, FunctionalState NewState) |
| Configures the DMA2D dead time. More... | |
| void | DMA2D_LineWatermarkConfig (uint32_t DMA2D_LWatermarkConfig) |
| Define the configuration of the line watermark . More... | |
| void | DMA2D_ITConfig (uint32_t DMA2D_IT, FunctionalState NewState) |
| Enables or disables the specified DMA2D's interrupts. More... | |
| FlagStatus | DMA2D_GetFlagStatus (uint32_t DMA2D_FLAG) |
| Checks whether the specified DMA2D's flag is set or not. More... | |
| void | DMA2D_ClearFlag (uint32_t DMA2D_FLAG) |
| Clears the DMA2D's pending flags. More... | |
| ITStatus | DMA2D_GetITStatus (uint32_t DMA2D_IT) |
| Checks whether the specified DMA2D's interrupt has occurred or not. More... | |
| void | DMA2D_ClearITPendingBit (uint32_t DMA2D_IT) |
| Clears the DMA2D's interrupt pending bits. More... | |
This file contains all the functions prototypes for the DMA2D firmware library.
Licensed under MCD-ST Liberty SW License Agreement V2, (the "License"); You may not use this file except in compliance with the License. You may obtain a copy of the License at:
http://www.st.com/software_license_agreement_liberty_v2
Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.
